Machine Features
◎ High speed, efficient, and low consumption
◎ Complete coil processing mode
◎ High reliability, low maintenance
◎ Low operating costs
◎ Replace acid pickling
Technical parameters:
Material to be blasted:Carbon structural steel,alloy structural steel,
Carbon tool steel,spring steel,bearing steel,high speed tool steel,
stainless steel(austenitic,ferritic,martensiticl,alloy tool steel.
Wire diameter range: 6.5 to 34mm,smaller(6.5mm) or bigger (34mm) diameters are possile to be basted as long as a sufficient spread can be done.
Coil outside diameter max:1500mm
Coil inside diameter min：750mm
Length of coil arms: 4200mm
|
Wire diameter |
6.5-8mm |
10-12mm |
14mm |
16mm |
20mm |
30mm |
34mm |
|
Coil Max weight(Kgs) |
1000 |
2000 |
2000 |
2000 |
2500 |
2500 |
2500 |
